STARTER MOTOR: The original Lucas starter motor fitted to the Td & TF was a M35G type part No 25022 with a inspection band, a threaded pinion nut and a thick cast steel drive end fixing plate. These can be reconditioned but we require the customer own unit first. The current starter motor LRS101 will fit the Td & TF engine with one minor modification. The through bolts holding the starter together and fitted with their heads and the pinion end and on some cylinder blocks foul the casing inside the starter housing. The casting can be ground away in the offending area to enable the starter to fit. It will not please the concurs buff as it has no band and a pressed steel steel end plate but is is economically priced and even the surcharge is low if you do not have an original unit.

DYNAMO: Two types of LUCAS dynamo were fitted as original equipment to the TD & TF. TDs from 1950 to 1952 were fitted with a C39PV number 22257A and from 1952 and all TFs a C39PV-2 number 22268A or B was fitted. The differences were in the two end brackets, the only important one being that the later commutator and bracket had a longer bush fitted. Original dynamos can be re-conditioned but we require the customers unit first.

Item

Description

Action

STARTER TD/F/MGA MIDGET

Product Code: LRS101

£116.70

£97.25 ex. VAT

each x

Hi Torq starter TD-TF 120 Tooth ring gear

Product Code: LRS101COMP

£239.94

£199.95 ex. VAT

each x

Recon OE Starter motor TD TF MGA

Product Code: LRS101OE

£101.40

£84.50 ex. VAT

each x

STARTER EX TD TF MGA *SUR50*

Product Code: 3H952E

Has been superseded by

STARTER TD/F/MGA MIDGET

Product Code: LRS101

£116.70

£97.25 ex. VAT

each x

Bush Starter motor drive end

Product Code: 7H5049

£3.54

£2.95 ex. VAT

each x

PLATE - NOT CURRENTLY AVAILABLE

Product Code: 27H6768

BUSH COMUTATOR END

Product Code: 511141

STARTER BRUSH SET MGA TD TF

Product Code: GSB102

£5.70

£4.75 ex. VAT

SET x

TENSION SPRING SET FOR BRUSHES - NLA

Product Code: 509819A

Pinion and Sleeve unit (9 tooth)

Product Code: 500892

£28.96

£24.13 ex. VAT

each x

INERTIA SPRING STARTER PINION

Product Code: 7H5045

£8.34

£6.95 ex. VAT

each x

FIELD COIL - NLA

Product Code: 7H5051

STARTER MOTOR ARMATURE

Product Code: 514026

£20.76

£17.30 ex. VAT

each x

ARMATURE - NLA

Product Code: 7H5050

STARTER CABLE

Product Code: CQB301

PER METRE

£9.54

£7.95 ex. VAT

METRE x

TROUGHT BOLT STARTER MOTOR NLA

Product Code: 17H5444

STARTER BRUSH SET MGA TD TF

Product Code: GSB102

£5.70

£4.75 ex. VAT

SET x

USE GSB102

Product Code: L251108

Has been superseded by

STARTER BRUSH SET MGA TD TF

Product Code: GSB102

£5.70

£4.75 ex. VAT

SET x

BOLT STARTER MOTOR XPAG

Product Code: CA1095

£1.97

£1.64 ex. VAT

each x

SPRING WASHER 3/8 INCH (PACK 10)

Product Code: GHF333

£0.18

£0.15 ex. VAT

Pack of 10 x

Dynamo TD TF New unit (15mm shaft) C39

Product Code: X24469B

£173.94

£144.95 ex. VAT

each x

O.E. Recon Dynamo TD TF (15mm shaft) C39

Product Code: X24469E

£299.94

£249.95 ex. VAT

each x

BRUSH SET FOR C39 DYNAMO

Product Code: GGB105

£3.54

£2.95 ex. VAT

each x

BRUSH SET FOR C39 DYNAMO

Product Code: GGB105

£3.54

£2.95 ex. VAT

each x

C40-C39 Rear bush Dynamo(15mm shaft)

Product Code: 7H5390

£8.10

£6.75 ex. VAT

each x

TENSION SPRING SET FOR BRUSHES NLA

Product Code: 7H5031

TENSION SPRING SET FOR BRUSHES NLA

Product Code: 7H5031

OILER FOR REAR OF DYNAMO

Product Code: 7H5527

£43.14

£35.95 ex. VAT

each x

C39-C40 Dynamo front Bearing

Product Code: 97H626

£9.08

£7.57 ex. VAT

each x

DYNAMO BRACKET - NLA

Product Code: 27H7647

WOODRUFF KEY

Product Code: WKN404

£1.02

£0.85 ex. VAT

each x

NUT 7/16 inch Thin Type

Product Code: NT607041

£0.61

£0.51 ex. VAT

each x

SPRING WASHER 7/16 INCH

Product Code: GHF334

£0.24

£0.20 ex. VAT

each x

PULLEY WITH FAN TC/Early TD

Product Code: X24468

£78.60

£65.50 ex. VAT

each x

Dynamo pulley late TD&TF (15mm)

Product Code: AAA5839

£46.20

£38.50 ex. VAT

each x

FAN DYNAMO TD TF MGA

Product Code: AEC82

Has been superseded by

DYNAMO FAN

Product Code: 17D11

£14.29

£11.91 ex. VAT

each x

DYNAMO THROUGH BOLT - NLA

Product Code: 242675A

SUNDRY PART KIT - DYNAMO - NLA

Product Code: 37H6836

COVER PLATE - DYNAMO TC

Product Code: X22042

£45.36

£37.80 ex. VAT

each x

FAN BELT T TYPE

Product Code: X24094

£22.02

£18.35 ex. VAT

each x

BRACKET DYNAMO TO BLOCK

Product Code: AAA5684

£40.60

£33.83 ex. VAT

each x

TB-TC-TD-TF Dynamo adjusting link

Product Code: AAA5831

£23.94

£19.95 ex. VAT

each x

REAR COVER PLATE SCREW T TYPE

Product Code: CA1122

£4.14

£3.45 ex. VAT

each x

REAR COVER PLATE SCREW T TYPE

Product Code: CA1122

£4.14

£3.45 ex. VAT

each x

SPRING WASHER 5/16 inch

Product Code: GHF332

£0.07

£0.06 ex. VAT

Pack of 10 x

S/STEEL SPRING WASHER 5/16 INCH

Product Code: GHF332SS

£0.12

£0.10 ex. VAT

each x

SPRING WASHER 5/16 inch

Product Code: GHF332

£0.07

£0.06 ex. VAT

Pack of 10 x

S/STEEL SPRING WASHER 5/16 INCH

Product Code: GHF332SS

£0.12

£0.10 ex. VAT

each x

SET SCREW 8mm x 1mm x 35mm

Product Code: MET8135

£1.02

£0.85 ex. VAT

each x

Plain hex nut 8mm

Product Code: CA1126

£1.38

£1.15 ex. VAT

each x

DISTANCE PIECE - NLA

Product Code: X24417

Plain hex nut 8mm

Product Code: CA1126

£1.38

£1.15 ex. VAT

each x

SET SCREW 5/16 INCH UNC X 0.625 INCH

Product Code: SH505051

Has been superseded by

5/16th UNC x 5/8 SS Set Screw

Product Code: SH505051SS

£0.42

£0.35 ex. VAT

each x

5/16th UNC x 5/8 SS Set Screw

Product Code: SH505051SS

£0.42

£0.35 ex. VAT

each x

PLAIN WASHER 5/16 INCH x 1 INCH OD

Product Code: PWZ205

Has been superseded by

WASHER S/STEEL PLAIN 5/16 INCH x 1 INCH OD

Product Code: PWZ205SS

£0.24

£0.20 ex. VAT

each x

WASHER S/STEEL PLAIN 5/16 INCH x 1 INCH OD

Product Code: PWZ205SS

£0.24

£0.20 ex. VAT

each x

PLAIN WASHER 5/16 INCH x 1 INCH OD

Product Code: PWZ205

Has been superseded by

WASHER S/STEEL PLAIN 5/16 INCH x 1 INCH OD

Product Code: PWZ205SS

£0.24

£0.20 ex. VAT

each x

WASHER S/STEEL PLAIN 5/16 INCH x 1 INCH OD

Product Code: PWZ205SS

£0.24

£0.20 ex. VAT

each x

Reduction box Revcounter drive TC-TD-TF

Product Code: 27H210

£106.80

£89.00 ex. VAT

each x

COUPLING KIT

Product Code: 27H211K

£17.29

£14.41 ex. VAT

SET x

GREASE NIPPLE 3/16 INCH STRAIGHT - NLA

Product Code: UHN300

REV COUNTER DRIVE CABLE TD TC

Product Code: 27H209

£46.62

£38.85 ex. VAT

each x

REV COUNTER CABLE RHD TF

Product Code: ACG5080

£46.62

£38.85 ex. VAT

each x

REV COUNTER CABLE LHD TF

Product Code: ACG5083

£41.60

£34.67 ex. VAT

each x

Products not on diagram

FIELD COIL - NLA

Product Code: AAU9326

PINION DRIVE INERTIA STARTER

Product Code: BAU2074

£23.00

£19.17 ex. VAT

each x

STARTER BRUSH SET MIDG MGA T

Product Code: GSB105

£4.98

£4.15 ex. VAT

each x

Alternator/Dynamo with rear rev drive TD/TF

Product Code: X24469ALT

£594.00

£495.00 ex. VAT

each x

TB-TF dynamo mount bolt kit

Product Code: EBK2010

£21.17

£17.64 ex. VAT

KIT x

C45 Dynalite Negative Earth with Tacho Drive

Product Code: BGT1000NE

C45 Dynalite Positive Earth with Tacho Drive

Product Code: BGT1000PE
